Engineering Apple III Bare Board

The following is an image of the of pre-production engineering "bare board" for the Apple III in its earliest development phases in 1978. This board resides in the private collection of Daniel Kottke who loaned it to the DigiBarn for scanning and online access. More on this very historical artifact below.

Front of Modified Grounding board
click here for super high resolution image
